Sundown Audio U-12 D2 12" 1500W RMS Dual 2-Ohm U-Series Subwoofer

The Sundown U Series is our premier “standard suspension” woofer series. It is the most direct replacement for the world famous Z v.3 woofer line which we produced from 2011 to 2016 before launching the “new platform” Z v.4 series. Due to numerous advancements in our design process the U Series is able to deliver performance on-par with the Z v.3 series but at a much lower cost.

We start with a double-stacked / 8.66” wide Y35 grade ferrite magnet system coupled to a one-piece, bumped T-Yoke and a 0.6” thick top-plate. Just as with the Z v.3 before it and our other high-end subwoofers we also add a very thick (5mm thickness) aluminum shorting ring inside the magnets to reduce static inductance and level out inductance over stroke. The U series motor also features a 0.6” long pole-extension to keep the coil under control at high levels of excursion.

The voice coil is a 2.36” long / 3” diameter 4-layer aluminum winding / aluminum former unit – which is the same coil we use in our X v.2 series and, thus, the U series has the same 1500-watt RMS ratings. The coil temperature is kept in check by a heavily smoothed / high-velocity pole-vent and a series of ten direct air-gap vents in the back plate. The U series also features newly tooled cast aluminum vent rings in between the frame and top plate to effectively exchange air at a high velocity over the voice coil beneath the spider landing.

The U series features an all-new cast aluminum frame series to the Sundown line which allows for taller cones than the older frames used on the Z v.3 series. The taller cones provide enhanced coil stability and increased mechanical excursion capability. We also tooled matching cast-aluminum surround clamps for the U series to ensure durability in the most demanding situations. The surrounds and cone bodies have been fully custom tooled especially for the U series and are stronger / support more excursion than the Z v.3 series cones and surrounds. The new cone bodies also feature an indentation for the same wide-flange, ultra-strong dust caps as our new platform subwoofers.

If you are looking for a woofer that sounds similar to the SA series but handles significantly more power… the U series is exactly what you need. It has been designed to live up to the reputation earned by our Z v.3 series both in terms of every-day music enjoyment and SPL competition.

Features & Technology:

• Xmax = 30mm one-way by 70% BL
• RMS Power = 1500-watts
• Heavily vented magnetic gap
• Optimized high-velocity pole vent
• Innovative high-velocity vented frame spacer ring
• Black Aluminum 3” voice coil former for superior heat dissipation
• High Temperature 4-Layer Round Wire Coil
• Large aluminum Faraday Ring (Magnet ID)
• Spring Loaded Terminals
• Stitched-On Double-XL Tinsel Leads to prevent fatigue and failure
• Bolted-On Surrounds
• Bolted-On 100% Nomex Spiders
• High-Strength Cast Aluminum Frame
• Optimized for small ported & band-pass enclosures

Specifications:

• 1500 Watts RMS
• Linear X-Max by 70% BL : 30 mm one-way
• Mounting Depth: 7.75"
• Mounting Diameter: 11.10"
• Outside Diameter: 12.83"
• Magnet Diameter: 8.66"
• Weight: 47LB

Enclosure Recommendations:

• Recommended Box Specs (Sealed): 1.0ft^3 (Yields F3 of 46Hz)
• Recommended Box Specs (Ported): 2.0ft^3 (Tune to 35Hz, yields F3 of 28Hz)
